Title

layout: true
<slide-template title="Quantum Computing" subtitle="Introduction into Quantum Machine Learning: Data Encoding, Model, Measurement"></slide-template>

---
class: title-slide, center, middle

<title-slide titletype="Lecture" title="Quantum Computing" modulenumber="(CS5070)" subtitle="Introduction into Quantum Machine Learning: Data Encoding, Model, Measurement"></title-slide>

---
# .darkblue[Influences to Machine Learning]

<div class="textcenter padding-bottom">
<img src="../../img/qc/ml/InfluencesToML.svg" align="top" class="fullwidth"></img>
</div>
<div class="textcenter darkblue em">
"Learning patterns from data in order to draw inferences"
</div>

---
# .darkblue[Machine Learning] - Basics

--
.more-more-condensed[
- .darkblue[How to choose a model?]
- .darkblue[How to find optimal parameters?]
]

--
.more-more-condensed[
.darkblue[Follow-up questions] related to quantum computing:
- .darkblue[Are there quantum models?]
- .darkblue[Can quantum computing be utilized to find optimal parameters?]
]

---
# Machine Learning .darkblue[Ingredients: Data]

.more-more-condensed.darkblue[
- <span class="material-icons">photo_library</span> Pictures
- <span class="material-icons">video_library</span> Videos
- <span class="material-icons">backup_table</span> Spreadsheets
- <span class="material-icons">pin</span> Numerical/Categorical
- <span class="material-icons">description</span> Texts in Natural Language
   - <span class="material-icons padding-left">picture_as_pdf</span> Scientific Publications
   - <span class="material-icons padding-left">email</span> EMail
   - <span class="material-icons padding-left">chat</span> Chat Communications
  - ...
- <span class="material-icons">terminal</span> Source Code
- ...
]

---
# Machine Learning .darkblue[Ingredients: Data]

.reference[Adapted from <a href="https://github.com/qiskit-community/qiskit-presentations/tree/master/2021-11-29_12-02_eqtc" target="_blank">A. Dekusar, J. Gacon, Qiskit Machine Learning: Quantum algorithms for supervised learning, EQTC, 2022</a> <a href="https://pixabay.com/de/illustrations/natur-tier-katze-inl%c3%a4ndisch-4779493/" target="_blank">Picture Source</a>]

.more-more-condensed[
<table>
<tbody>
<tr>
<td class="darkblue textcenter bold halfwidth">Picture</td>
<td class="darkblue textcenter bold halfwidth">Dataset</td>
</tr>
<tr>
<td><div class="textcenter">
<table>
<tbody>
<tr>
<td class="halfwidth"><div class="round-border blue-border"><img src="../../img/qc/ml/nature-gc83b4b57c_640.jpg" align="top" class="fullwidth"></img></div></td>
<td class="halfwidth padding-left" style="text-align:left">$n$ pixels</td>
</tr>
<tr>
<td>$m$ pixels</td></tr></tbody></table>
</div>
.small-font[
- Every pixel $\in[-1,1]$ from black to white
- Every image as vector:<br/>
<table><tbody><tr><td>
$x_1 := \left[\begin{array}{c} -0.6\\ +0.32\\ ...\\ -0.99 \end{array}\right]$
</td><td>
$n\cdot m$ elements (in this context also called .em[features])
</td></tr></tbody></table>
]
</td>
<td style="vertical-align:top">
.small-font[
- A dataset $D$ consists of many images: $(x_1,...,x_N)$
- Every image is a sample with $N$ samples in total
- Huge matrix to represent all images:<br/>
$D=\left[\begin{array}{c} x_1 & x_2 & ...& x_N \end{array}\right]$<br/>
$=\left[\begin{array}{cccc} -0.6 & +0.12 & ... & +0.55 \\\\ +0.32 & +1 & ... & -0.38 \\\\ ...&...&...&...\\\\ -0.99 & +0.03 & ... & +0.22 \end{array}\right]$
<dic class="textcenter">Matrix of size $N\times n\cdot m$</div>
]
</td>
</tr>
</tbody>
</table>
]

---
# Machine Learning .darkblue[Ingredients: Model]

.more-more-condensed[
- A .darkblue[model is] a .darkblue[function that takes data, depends on some parameters and maps this data to] some .darkblue[prediction]<br/>
<div class="textcenter padding-top"><img src="../../img/qc/ml/Prediction.svg" align="top" style="width:75%"></img></div>
]

---
# Machine Learning .darkblue[Ingredients: Data and Quantum Model]

.more-more-condensed[
- Possibilities of involving Quantum Computing:
<div class="padding-top">
<table class="result tablepadding textcenter">
<tbody>
<tr>
<th></th><th></th><th colspan="2">Data Processing</th>
</tr>
<tr>
<th></th><th></th><td class="darkgreen">Classical</td><td class="darkred">Quantum</td>
</tr>
<tr>
<th rowspan="2" style="border-radius: 0px 0px 0px 5px;">Representation of data</th><td class="darkgreen">Classical</td><td class="darkgreen">CC</td><td>.darkgreen[C].darkred[Q]</td>
</tr>
<tr>
<td class="darkred">Quantum</td><td>.darkred[Q].darkgreen[C]</td><td class="darkred">QQ</td>
</tr>
</tbody>
</table>
</div>
]

---
# How can we .darkblue[encode data and build] a .darkblue[quantum model]?

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a>]

.more-more-condensed[
<div class="textcenter">
<img src="../../img/qc/ml/QuantumModel.svg" align="top" class="fullwidth"></img>
</div>
]

---
# How can we .darkblue[encode data and build] a .darkblue[quantum model]? - .darkblue[Data encoding]

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a>]

.more-more-condensed[
<div class="textcenter">
<img src="../../img/qc/ml/QuantumModelData.svg" align="top" class="fullwidth"></img>
</div>
]

---
# .darkblue[How to encode data $x$?]

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a>]

<div class="textcenter">
$x$<br/><svg-arrow orientation="down" color="darkblue" scale="0.1"></svg-arrow><br/>$|\psi\rangle = \alpha_0\cdot|0\rangle+\alpha_1\cdot|1\rangle+\cdots+\alpha_k\cdot|k\rangle$<br/>???
</div>

---
# How to encode data $x$? - .darkblue[Basis encoding]

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a>]

.more-more-condensed[
<table>
<tbody>
<tr>
<td class="darkblue bold" style="width:50%">Idea</td>
<td class="darkblue bold" style="width:50%">Example</td>
</tr>
<tr>
<td class="darkblue small-font22">Encode .em[binary] representation of data in basis states</td>
<td class="darkblue small-font22">Data $x$ with 2 features</td>
</tr>
<tr>
<td class="small-font textcenter">$x=\left[\begin{array}{c} x_1 \\ x_2 \\ \vdots \\ x_k \end{array}\right]=\left[\begin{array}{c} b_{1,1}\cdots b_{1,n} \\ b_{2,1}\cdots b_{2,n} \\ \vdots \\  b_{k,1}\cdots b_{k,n} \end{array}\right]$</td>
<td class="small-font textcenter">$x=\left[\begin{array}{c} 1 \\ 3 \end{array}\right]=\left[\begin{array}{c} 01_b \\ 11_b \end{array}\right]$</td>
</tr>
<tr>
<td class="textcenter"><svg-arrow orientation="down" color="darkblue" scale="0.05"></svg-arrow></td>
<td class="textcenter"><svg-arrow orientation="down" color="darkblue" scale="0.05"></svg-arrow></td>
</tr>
<tr>
<td class="small-font textcenter">$|x\rangle=|b_{1,1}\cdots b_{1,n}\cdots b_{k,1}\cdots b_{k,n}\rangle$</td>
<td class="small-font textcenter">$|x\rangle=|0111\rangle$</td>
</tr>
<tr>
<td class="textcenter">Circuit: <img src="../../img/qc/ml/BasisEncodingGeneral.svg" align="top" style="width:6em"></img></td>
<td class="textcenter">Circuit: <img src="../../img/qc/ml/BasisEncodingExample.svg" align="top" style="width:4em"></img></td>
</tr>
<tr>
<td class="padding-right"><div class="round-border green-border">.darkgreen.bold[Pro:]<br/>.darkblue[Easy to load]</div></td>
<td class="padding-left"><div class="round-border red-border">.darkred.bold[Contra:]<br/>.darkblue[.small-font[$k\cdot n$] qubits for .small-font[$k\cdot n$] bits]</div></td>
</tr>
</tbody>
</table>
]

---
# How to encode data $x$? - .darkblue[Amplitude encoding]

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a>]

.more-more-condensed[
<table>
<tbody>
<tr>
<td class="darkblue bold" style="width:50%">Idea</td>
<td class="darkblue bold" style="width:50%">Example</td>
</tr>
<tr>
<td class="darkblue">Encode .em[normalized] data in state amplitudes</td>
<td class="darkblue">Data $x$ with 4 features</td>
</tr>
<tr>
<td class="small-font textcenter">

<svg xmlns="http://www.w3.org/2000/svg" width="188.792px" height="98.352px" viewBox="0 -2967 10430.6 5434" xmlns:xlink="http://www.w3.org/1999/xlink" style="" transform="scale(1.5)"><defs><path id="MJX-4-TEX-I-78" d="M52 289Q59 331 106 386T222 442Q257 442 286 424T329 379Q371 442 430 442Q467 442 494 420T522 361Q522 332 508 314T481 292T458 288Q439 288 427 299T415 328Q415 374 465 391Q454 404 425 404Q412 404 406 402Q368 386 350 336Q290 115 290 78Q290 50 306 38T341 26Q378 26 414 59T463 140Q466 150 469 151T485 153H489Q504 153 504 145Q504 144 502 134Q486 77 440 33T333 -11Q263 -11 227 52Q186 -10 133 -10H127Q78 -10 57 16T35 71Q35 103 54 123T99 143Q142 143 142 101Q142 81 130 66T107 46T94 41L91 40Q91 39 97 36T113 29T132 26Q168 26 194 71Q203 87 217 139T245 247T261 313Q266 340 266 352Q266 380 251 392T217 404Q177 404 142 372T93 290Q91 281 88 280T72 278H58Q52 284 52 289Z"></path><path id="MJX-4-TEX-S4-2192" d="M56 237T56 250T70 270H835Q719 357 692 493Q692 494 692 496T691 499Q691 511 708 511H711Q720 511 723 510T729 506T732 497T735 481T743 456Q765 389 816 336T935 261Q944 258 944 250Q944 244 939 241T915 231T877 212Q836 186 806 152T761 85T740 35T732 4Q730 -6 727 -8T711 -11Q691 -11 691 0Q691 7 696 25Q728 151 835 230H70Q56 237 56 250Z"></path><path id="MJX-4-TEX-S4-2212" d="M84 237T84 250T98 270H679Q694 262 694 250T679 230H98Q84 237 84 250Z"></path><path id="MJX-4-TEX-N-6E" d="M41 46H55Q94 46 102 60V68Q102 77 102 91T102 122T103 161T103 203Q103 234 103 269T102 328V351Q99 370 88 376T43 385H25V408Q25 431 27 431L37 432Q47 433 65 434T102 436Q119 437 138 438T167 441T178 442H181V402Q181 364 182 364T187 369T199 384T218 402T247 421T285 437Q305 442 336 442Q450 438 463 329Q464 322 464 190V104Q464 66 466 59T477 49Q498 46 526 46H542V0H534L510 1Q487 2 460 2T422 3Q319 3 310 0H302V46H318Q379 46 379 62Q380 64 380 200Q379 335 378 343Q372 371 358 385T334 402T308 404Q263 404 229 370Q202 343 195 315T187 232V168V108Q187 78 188 68T191 55T200 49Q221 46 249 46H265V0H257L234 1Q210 2 183 2T145 3Q42 3 33 0H25V46H41Z"></path><path id="MJX-4-TEX-N-6F" d="M28 214Q28 309 93 378T250 448Q340 448 405 380T471 215Q471 120 407 55T250 -10Q153 -10 91 57T28 214ZM250 30Q372 30 372 193V225V250Q372 272 371 288T364 326T348 362T317 390T268 410Q263 411 252 411Q222 411 195 399Q152 377 139 338T126 246V226Q126 130 145 91Q177 30 250 30Z"></path><path id="MJX-4-TEX-N-72" d="M36 46H50Q89 46 97 60V68Q97 77 97 91T98 122T98 161T98 203Q98 234 98 269T98 328L97 351Q94 370 83 376T38 385H20V408Q20 431 22 431L32 432Q42 433 60 434T96 436Q112 437 131 438T160 441T171 442H174V373Q213 441 271 441H277Q322 441 343 419T364 373Q364 352 351 337T313 322Q288 322 276 338T263 372Q263 381 265 388T270 400T273 405Q271 407 250 401Q234 393 226 386Q179 341 179 207V154Q179 141 179 127T179 101T180 81T180 66V61Q181 59 183 57T188 54T193 51T200 49T207 48T216 47T225 47T235 46T245 46H276V0H267Q249 3 140 3Q37 3 28 0H20V46H36Z"></path><path id="MJX-4-TEX-N-6D" d="M41 46H55Q94 46 102 60V68Q102 77 102 91T102 122T103 161T103 203Q103 234 103 269T102 328V351Q99 370 88 376T43 385H25V408Q25 431 27 431L37 432Q47 433 65 434T102 436Q119 437 138 438T167 441T178 442H181V402Q181 364 182 364T187 369T199 384T218 402T247 421T285 437Q305 442 336 442Q351 442 364 440T387 434T406 426T421 417T432 406T441 395T448 384T452 374T455 366L457 361L460 365Q463 369 466 373T475 384T488 397T503 410T523 422T546 432T572 439T603 442Q729 442 740 329Q741 322 741 190V104Q741 66 743 59T754 49Q775 46 803 46H819V0H811L788 1Q764 2 737 2T699 3Q596 3 587 0H579V46H595Q656 46 656 62Q657 64 657 200Q656 335 655 343Q649 371 635 385T611 402T585 404Q540 404 506 370Q479 343 472 315T464 232V168V108Q464 78 465 68T468 55T477 49Q498 46 526 46H542V0H534L510 1Q487 2 460 2T422 3Q319 3 310 0H302V46H318Q379 46 379 62Q380 64 380 200Q379 335 378 343Q372 371 358 385T334 402T308 404Q263 404 229 370Q202 343 195 315T187 232V168V108Q187 78 188 68T191 55T200 49Q221 46 249 46H265V0H257L234 1Q210 2 183 2T145 3Q42 3 33 0H25V46H41Z"></path><path id="MJX-4-TEX-N-61" d="M137 305T115 305T78 320T63 359Q63 394 97 421T218 448Q291 448 336 416T396 340Q401 326 401 309T402 194V124Q402 76 407 58T428 40Q443 40 448 56T453 109V145H493V106Q492 66 490 59Q481 29 455 12T400 -6T353 12T329 54V58L327 55Q325 52 322 49T314 40T302 29T287 17T269 6T247 -2T221 -8T190 -11Q130 -11 82 20T34 107Q34 128 41 147T68 188T116 225T194 253T304 268H318V290Q318 324 312 340Q290 411 215 411Q197 411 181 410T156 406T148 403Q170 388 170 359Q170 334 154 320ZM126 106Q126 75 150 51T209 26Q247 26 276 49T315 109Q317 116 318 175Q318 233 317 233Q309 233 296 232T251 223T193 203T147 166T126 106Z"></path><path id="MJX-4-TEX-N-6C" d="M42 46H56Q95 46 103 60V68Q103 77 103 91T103 124T104 167T104 217T104 272T104 329Q104 366 104 407T104 482T104 542T103 586T103 603Q100 622 89 628T44 637H26V660Q26 683 28 683L38 684Q48 685 67 686T104 688Q121 689 141 690T171 693T182 694H185V379Q185 62 186 60Q190 52 198 49Q219 46 247 46H263V0H255L232 1Q209 2 183 2T145 3T107 3T57 1L34 0H26V46H42Z"></path><path id="MJX-4-TEX-N-69" d="M69 609Q69 637 87 653T131 669Q154 667 171 652T188 609Q188 579 171 564T129 549Q104 549 87 564T69 609ZM247 0Q232 3 143 3Q132 3 106 3T56 1L34 0H26V46H42Q70 46 91 49Q100 53 102 60T104 102V205V293Q104 345 102 359T88 378Q74 385 41 385H30V408Q30 431 32 431L42 432Q52 433 70 434T106 436Q123 437 142 438T171 441T182 442H185V62Q190 52 197 50T232 46H255V0H247Z"></path><path id="MJX-4-TEX-N-7A" d="M42 263Q44 270 48 345T53 423V431H393Q399 425 399 415Q399 403 398 402L381 378Q364 355 331 309T265 220L134 41L182 40H206Q254 40 283 46T331 77Q352 105 359 185L361 201Q361 202 381 202H401V196Q401 195 393 103T384 6V0H209L34 1L31 3Q28 8 28 17Q28 30 29 31T160 210T294 394H236Q169 393 152 388Q127 382 113 367Q89 344 82 264V255H42V263Z"></path><path id="MJX-4-TEX-N-65" d="M28 218Q28 273 48 318T98 391T163 433T229 448Q282 448 320 430T378 380T406 316T415 245Q415 238 408 231H126V216Q126 68 226 36Q246 30 270 30Q312 30 342 62Q359 79 369 104L379 128Q382 131 395 131H398Q415 131 415 121Q415 117 412 108Q393 53 349 21T250 -11Q155 -11 92 58T28 218ZM333 275Q322 403 238 411H236Q228 411 220 410T195 402T166 381T143 340T127 274V267H333V275Z"></path><path id="MJX-4-TEX-N-3D" d="M56 347Q56 360 70 367H707Q722 359 722 347Q722 336 708 328L390 327H72Q56 332 56 347ZM56 153Q56 168 72 173H708Q722 163 722 153Q722 140 707 133H70Q56 140 56 153Z"></path><path id="MJX-4-TEX-S4-23A1" d="M319 -645V1154H666V1070H403V-645H319Z"></path><path id="MJX-4-TEX-S4-23A3" d="M319 -644V1155H403V-560H666V-644H319Z"></path><path id="MJX-4-TEX-S4-23A2" d="M319 0V602H403V0H319Z"></path><path id="MJX-4-TEX-N-31" d="M213 578L200 573Q186 568 160 563T102 556H83V602H102Q149 604 189 617T245 641T273 663Q275 666 285 666Q294 666 302 660V361L303 61Q310 54 315 52T339 48T401 46H427V0H416Q395 3 257 3Q121 3 100 0H88V46H114Q136 46 152 46T177 47T193 50T201 52T207 57T213 61V578Z"></path><path id="MJX-4-TEX-N-32" d="M109 429Q82 429 66 447T50 491Q50 562 103 614T235 666Q326 666 387 610T449 465Q449 422 429 383T381 315T301 241Q265 210 201 149L142 93L218 92Q375 92 385 97Q392 99 409 186V189H449V186Q448 183 436 95T421 3V0H50V19V31Q50 38 56 46T86 81Q115 113 136 137Q145 147 170 174T204 211T233 244T261 278T284 308T305 340T320 369T333 401T340 431T343 464Q343 527 309 573T212 619Q179 619 154 602T119 569T109 550Q109 549 114 549Q132 549 151 535T170 489Q170 464 154 447T109 429Z"></path><path id="MJX-4-TEX-N-22EE" d="M78 30Q78 54 95 72T138 90Q162 90 180 74T199 31Q199 6 182 -12T139 -30T96 -13T78 30ZM78 440Q78 464 95 482T138 500Q162 500 180 484T199 441Q199 416 182 398T139 380T96 397T78 440ZM78 840Q78 864 95 882T138 900Q162 900 180 884T199 841Q199 816 182 798T139 780T96 797T78 840Z"></path><path id="MJX-4-TEX-I-6B" d="M121 647Q121 657 125 670T137 683Q138 683 209 688T282 694Q294 694 294 686Q294 679 244 477Q194 279 194 272Q213 282 223 291Q247 309 292 354T362 415Q402 442 438 442Q468 442 485 423T503 369Q503 344 496 327T477 302T456 291T438 288Q418 288 406 299T394 328Q394 353 410 369T442 390L458 393Q446 405 434 405H430Q398 402 367 380T294 316T228 255Q230 254 243 252T267 246T293 238T320 224T342 206T359 180T365 147Q365 130 360 106T354 66Q354 26 381 26Q429 26 459 145Q461 153 479 153H483Q499 153 499 144Q499 139 496 130Q455 -11 378 -11Q333 -11 305 15T277 90Q277 108 280 121T283 145Q283 167 269 183T234 206T200 217T182 220H180Q168 178 159 139T145 81T136 44T129 20T122 7T111 -2Q98 -11 83 -11Q66 -11 57 -1T48 16Q48 26 85 176T158 471L195 616Q196 629 188 632T149 637H144Q134 637 131 637T124 640T121 647Z"></path><path id="MJX-4-TEX-S4-23A4" d="M0 1070V1154H347V-645H263V1070H0Z"></path><path id="MJX-4-TEX-S4-23A6" d="M263 -560V1155H347V-644H0V-560H263Z"></path><path id="MJX-4-TEX-S4-23A5" d="M263 0V602H347V0H263Z"></path></defs><g stroke="currentColor" fill="currentColor" stroke-width="0" transform="matrix(1 0 0 -1 0 0)"><g data-mml-node="math"><g data-mml-node="mi"><use xlink:href="#MJX-4-TEX-I-78"></use></g><g data-mml-node="mover" transform="translate(849.8, 0)"><g data-mml-node="mo"><use xlink:href="#MJX-4-TEX-S4-2192" transform="translate(3657.1, 0)"></use><svg width="3757.1" height="865" x="0" y="-182" viewBox="939.3 -182 3757.1 865"><use xlink:href="#MJX-4-TEX-S4-2212" transform="scale(7.244, 1)"></use></svg></g><g data-mml-node="mpadded" transform="translate(0, 783) scale(0.707)"><g transform="translate(277.8, 150)"><g data-mml-node="mstyle" transform="scale(1.414)"><g data-mml-node="mtext"><use xlink:href="#MJX-4-TEX-N-6E"></use><use xlink:href="#MJX-4-TEX-N-6F" transform="translate(556, 0)"></use><use xlink:href="#MJX-4-TEX-N-72" transform="translate(1056, 0)"></use><use xlink:href="#MJX-4-TEX-N-6D" transform="translate(1448, 0)"></use><use xlink:href="#MJX-4-TEX-N-61" transform="translate(2281, 0)"></use><use xlink:href="#MJX-4-TEX-N-6C" transform="translate(2781, 0)"></use><use xlink:href="#MJX-4-TEX-N-69" transform="translate(3059, 0)"></use><use xlink:href="#MJX-4-TEX-N-7A" transform="translate(3337, 0)"></use><use xlink:href="#MJX-4-TEX-N-65" transform="translate(3781, 0)"></use></g></g></g></g></g><g data-mml-node="mi" transform="translate(5784.7, 0)"><use xlink:href="#MJX-4-TEX-I-78"></use></g><g data-mml-node="mo" transform="translate(6634.5, 0)"><use xlink:href="#MJX-4-TEX-N-3D"></use></g><g data-mml-node="mrow" transform="translate(7690.2, 0)"><g data-mml-node="mo"><use xlink:href="#MJX-4-TEX-S4-23A1" transform="translate(104, 1813)"></use><use xlink:href="#MJX-4-TEX-S4-23A3" transform="translate(104, -1823)"></use><svg width="667" height="2036" y="-768" x="104" viewBox="0 509 667 2036"><use xlink:href="#MJX-4-TEX-S4-23A2" transform="scale(1, 5.073)"></use></svg></g><g data-mml-node="mtable" transform="translate(875, 0)"><g data-mml-node="mtr" transform="translate(0, 2217)"><g data-mml-node="mtd" transform="translate(7.4, 0)"><g data-mml-node="msub"><g data-mml-node="mi"><use xlink:href="#MJX-4-TEX-I-78"></use></g><g data-mml-node="mn" transform="translate(572, -150) scale(0.707)"><use xlink:href="#MJX-4-TEX-N-31"></use></g></g></g></g><g data-mml-node="mtr" transform="translate(0, 922.3)"><g data-mml-node="mtd" transform="translate(7.4, 0)"><g data-mml-node="msub"><g data-mml-node="mi"><use xlink:href="#MJX-4-TEX-I-78"></use></g><g data-mml-node="mn" transform="translate(572, -150) scale(0.707)"><use xlink:href="#MJX-4-TEX-N-32"></use></g></g></g></g><g data-mml-node="mtr" transform="translate(0, -922.3)"><g data-mml-node="mtd" transform="translate(356.2, 0)"><g data-mml-node="TeXAtom"><g data-mml-node="mo"><use xlink:href="#MJX-4-TEX-N-22EE"></use></g></g></g></g><g data-mml-node="mtr" transform="translate(0, -2217)"><g data-mml-node="mtd"><g data-mml-node="msub"><g data-mml-node="mi"><use xlink:href="#MJX-4-TEX-I-78"></use></g><g data-mml-node="mi" transform="translate(572, -150) scale(0.707)"><use xlink:href="#MJX-4-TEX-I-6B"></use></g></g></g></g></g><g data-mml-node="mo" transform="translate(1865.4, 0)"><use xlink:href="#MJX-4-TEX-S4-23A4" transform="translate(104, 1813)"></use><use xlink:href="#MJX-4-TEX-S4-23A6" transform="translate(104, -1823)"></use><svg width="667" height="2036" y="-768" x="104" viewBox="0 509 667 2036"><use xlink:href="#MJX-4-TEX-S4-23A5" transform="scale(1, 5.073)"></use></svg></g></g></g></g></svg>
</td>
<td class="small-font textcenter">$x=\left[\begin{array}{c} 3.0 \\ 1.0 \\ 4.0 \\2.0 \end{array}\right]$</td>
</tr>
<tr>
<td class="textcenter"><svg-arrow orientation="down" color="darkblue" scale="0.05"></svg-arrow></td>
<td class="textcenter"><svg-arrow orientation="down" color="darkblue" scale="0.05"></svg-arrow></td>
</tr>
<tr>
<td class="small-font textcenter">$|\Phi_x\rangle=\sum_{i=0}^{2^n-1}x_{i+1}|i\rangle$</td>
<td class="small-font textcenter">$|\Phi_x\rangle=\frac{3.0\cdot|00\rangle+1.0\cdot|01\rangle+4.0\cdot|10\rangle+2.0\cdot|11\rangle}{\sqrt{3.0^2+1.0^2+4.0^2+2.0^2}}$</td>
</tr>
<tr>
<td class="padding-right"><div class="round-border green-border">.darkgreen.bold[Pro:]<br/>.darkblue[.small-font[$\lceil log(k)\rceil$] qubits for .small-font[$k$] features]</div></td>
<td class="padding-left"><div class="round-border red-border">.darkred.bold[Contra:]<br/>.darkblue[Difficult to load!]</div></td>
</tr>
</tbody>
</table>
]

---
# How to encode data $x$? - .darkblue[Angle encoding]

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a> <a href="https://arxiv.org/abs/1803.07128" target="_blank">[SK'18]</a> <a href="https://arxiv.org/abs/1804.11326" target="_blank">[H+'18]</a>]

.more-more-condensed[
- .darkblue[.bold[Idea:] Encode] (normalized) .darkblue[data in rotation angles]<br/>
<table><tbody><tr><td>$x=\left[\begin{array}{c} x_1 \\\\ x_2 \\\\ \vdots \\\\ x_k \end{array}\right]$</td><td><svg-arrow orientation="right" color="darkblue" scale="0.05"></svg-arrow></td><td><img src="../../img/qc/ml/AngleEncoding_k.svg" align="top" style="width:23em"></img></td></tr></tbody></table>
<div class="textcenter">
<img src="../../img/qc/ml/CosSin.svg" align="top" style="width:90%"></img>
</div>
]

---
# .darkblue[Feature Map via Angle Encoding]

.more-more-condensed[
- .darkblue.em.bold[Kernel trick:] A .darkblue[feature map can transform data into] a .darkblue[space]
  - .darkblue[where it is .em[easier to process]]
  - .darkblue[where features are .em[easier to be classified]] (by e.g. linear functions)

<div class="textcenter">
<img src="../../img/qc/ml/FeatureMap.svg" align="top" class="fullwidth"></img>
</div>
]

---
# .darkblue[Feature Maps] for other Class Positions than Quarter Circles 1/2

---
# .darkblue[Feature Maps] for other Class Positions than Quarter Circles 2/2

---
# .darkblue[Feature Maps] - Higher-Order Encodings

.more-more-condensed[
- Using .darkblue[non linear functions and entanglement] for feature map [Y+'20]<br/><img class="margin-top margin-bottom" src="../../img/qc/ml/HigherOrderFeatureMap.svg" align="top" style="width:75%"></img><div class="small-font">$u1(\phi)=diag(1,e^{-i\cdot\phi})=\left[\begin{array}{cc} 1 & 0 \\\\ 0 & e^{-i\cdot\phi} \end{array}\right],\phi_1(x) = x_1, \phi_2(x) = x_2$</div>
  <table class="result tablesmallpadding margin-top margin-bottom">
  <tbody>
  <tr>
  <th></th><th class="textcenter">1.</th><th class="textcenter">2.</th><th class="textcenter">3.</th><th class="textcenter">4.</th><th class="textcenter">5.</th>
  </tr>
  <tr>
  <th>$\phi_{1,2}(x)$</th>
  <td class="smaller-font">$\pi\cdot x_1\cdot x_2$</td>
  <td class="smaller-font">$\frac{\pi}{2}\cdot(1-x_1)\cdot(1-x_2)$</td>
  <td class="small-font">$e^{\frac{|x_1-x_2|^2\cdot ln(\pi)}{8}}$</td>
  <td class="smaller-font">$\frac{\pi}{3\cdot cos(x_1)\cdot cos(x_2)}$</td>
  <td class="smaller-font">$\pi\cdot cos(x_1)\cdot cos(x_2)$</td>
  </tr>
  </tbody>
  </table>

- More general forms like <a href="https://qiskit.org/documentation/stubs/qiskit.circuit.library.ZZFeatureMap.html" target="_blank">ZZFeatureMap</a> and <a href="https://qiskit.org/documentation/stubs/qiskit.circuit.library.PauliFeatureMap.html" target="_blank">PauliFeatureMap</a> (with a given number of repetitions) for more qubits
]

---
# .darkblue[Feature Maps] - Higher-Order Encodings

.more-more-condensed[
- .adrkblue[Classification accuracy] achieved .darkblue[by quantum SVM] [Y+'20]<br/>
.darkblue[Training] Accuracy .small-font[(= number of correct predictions / total number of predictions)]:<br/>
<table class="result tablepadding small-font margin-bottom" style="text-align:right">
<tbody>
<tr>
<th rowspan="2">Encoding Function</th><th colspan="4" class="textcenter">Dataset .em[(similar to)]</th>
</tr>
<tr>
<th>Circle</th><th>Exponential</th><th>Moon</th><th>XOR</th>
</tr>
<tr>
<th>1.</th><td>1.00</td><td>0.91</td><td>0.85</td><td>1.00</td>
</tr>
<tr>
<th>2.</th><td>1.00</td><td>0.93</td><td>0.96</td><td>0.97</td>
</tr>
<tr>
<th>3.</th><td>1.00</td><td>0.97</td><td>0.91</td><td>0.93</td>
</tr>
<tr>
<th>4.</th><td>1.00</td><td>0.98</td><td>1.00</td><td>0.95</td>
</tr>
<tr>
<th>5.</th><td>1.00</td><td>0.94</td><td>0.98</td><td>0.93</td>
</tr>
</tbody>
</table>
.darkblue[Test] Accuracy:<br/>
<table class="result tablepadding small-font" style="text-align:right">
<tbody>
<tr>
<th rowspan="2">Encoding Function</th><th colspan="4" class="textcenter">Dataset .em[(similar to)]</th>
</tr>
<tr>
<th>Circle</th><th>Exponential</th><th>Moon</th><th>XOR</th>
</tr>
<tr>
<th>1.</th><td>0.97</td><td>0.83</td><td>0.85</td><td>0.99</td>
</tr>
<tr>
<th>2.</th><td>0.96</td><td>0.89</td><td>0.87</td><td>0.96</td>
</tr>
<tr>
<th>3.</th><td>1.00</td><td>0.92</td><td>0.86</td><td>0.91</td>
</tr>
<tr>
<th>4.</th><td>1.00</td><td>0.88</td><td>0.92</td><td>0.89</td>
</tr>
<tr>
<th>5.</th><td>1.00</td><td>0.92</td><td>0.87</td><td>0.88</td>
</tr>
</tbody>
</table>
]

---
# Machine Learning .darkblue[Ingredients: Model]

.more-more-condensed[
- .darkblue[How good is your model] performing.darkblue[?]<br/>$\Rightarrow$ A .darkblue[.bold[cost function] .darkred.bold[$C(\hat{y},y)$] scores the model] based on model predictions and true value
  - .darkred.bold.small-font[$\hat{y}=f(x,\Theta)$] .darkblue[prediction] obtained from our model and
  - .darkred.bold.small-font[$y$] .darkblue[ground truth]
  - Alias: <span class="darkblue">loss function</span>, <span class="darkblue">error function</span>
- Usually: .darkblue[.bold[Minimize] cost function!]
- .darkblue[Widely used cost functions]
  - .darkblue[Mean Squared Error (MSE):] .darkred.bold.small-font[$MSE = (\hat{y}-y)^2$]
	 - being symmetric: an error above the target causes the same loss as the same magnitude of error below the target
  - .darkblue[Cross-Entropy Loss Function]
<svg xmlns="http://www.w3.org/2000/svg" width="202.576px" height="25.336px" viewBox="0 -950 11192.2 1400" xmlns:xlink="http://www.w3.org/1999/xlink" style="" class="darkred"><defs><path id="MJX-6-TEX-I-4C" d="M228 637Q194 637 192 641Q191 643 191 649Q191 673 202 682Q204 683 217 683Q271 680 344 680Q485 680 506 683H518Q524 677 524 674T522 656Q517 641 513 637H475Q406 636 394 628Q387 624 380 600T313 336Q297 271 279 198T252 88L243 52Q243 48 252 48T311 46H328Q360 46 379 47T428 54T478 72T522 106T564 161Q580 191 594 228T611 270Q616 273 628 273H641Q647 264 647 262T627 203T583 83T557 9Q555 4 553 3T537 0T494 -1Q483 -1 418 -1T294 0H116Q32 0 32 10Q32 17 34 24Q39 43 44 45Q48 46 59 46H65Q92 46 125 49Q139 52 144 61Q147 65 216 339T285 628Q285 635 228 637Z"></path><path id="MJX-6-TEX-I-43" d="M50 252Q50 367 117 473T286 641T490 704Q580 704 633 653Q642 643 648 636T656 626L657 623Q660 623 684 649Q691 655 699 663T715 679T725 690L740 705H746Q760 705 760 698Q760 694 728 561Q692 422 692 421Q690 416 687 415T669 413H653Q647 419 647 422Q647 423 648 429T650 449T651 481Q651 552 619 605T510 659Q484 659 454 652T382 628T299 572T226 479Q194 422 175 346T156 222Q156 108 232 58Q280 24 350 24Q441 24 512 92T606 240Q610 253 612 255T628 257Q648 257 648 248Q648 243 647 239Q618 132 523 55T319 -22Q206 -22 128 53T50 252Z"></path><path id="MJX-6-TEX-I-45" d="M492 213Q472 213 472 226Q472 230 477 250T482 285Q482 316 461 323T364 330H312Q311 328 277 192T243 52Q243 48 254 48T334 46Q428 46 458 48T518 61Q567 77 599 117T670 248Q680 270 683 272Q690 274 698 274Q718 274 718 261Q613 7 608 2Q605 0 322 0H133Q31 0 31 11Q31 13 34 25Q38 41 42 43T65 46Q92 46 125 49Q139 52 144 61Q146 66 215 342T285 622Q285 629 281 629Q273 632 228 634H197Q191 640 191 642T193 659Q197 676 203 680H757Q764 676 764 669Q764 664 751 557T737 447Q735 440 717 440H705Q698 445 698 453L701 476Q704 500 704 528Q704 558 697 578T678 609T643 625T596 632T532 634H485Q397 633 392 631Q388 629 386 622Q385 619 355 499T324 377Q347 376 372 376H398Q464 376 489 391T534 472Q538 488 540 490T557 493Q562 493 565 493T570 492T572 491T574 487T577 483L544 351Q511 218 508 216Q505 213 492 213Z"></path><path id="MJX-6-TEX-N-3D" d="M56 347Q56 360 70 367H707Q722 359 722 347Q722 336 708 328L390 327H72Q56 332 56 347ZM56 153Q56 168 72 173H708Q722 163 722 153Q722 140 707 133H70Q56 140 56 153Z"></path><path id="MJX-6-TEX-N-2212" d="M84 237T84 250T98 270H679Q694 262 694 250T679 230H98Q84 237 84 250Z"></path><path id="MJX-6-TEX-LO-2211" d="M60 948Q63 950 665 950H1267L1325 815Q1384 677 1388 669H1348L1341 683Q1320 724 1285 761Q1235 809 1174 838T1033 881T882 898T699 902H574H543H251L259 891Q722 258 724 252Q725 250 724 246Q721 243 460 -56L196 -356Q196 -357 407 -357Q459 -357 548 -357T676 -358Q812 -358 896 -353T1063 -332T1204 -283T1307 -196Q1328 -170 1348 -124H1388Q1388 -125 1381 -145T1356 -210T1325 -294L1267 -449L666 -450Q64 -450 61 -448Q55 -446 55 -439Q55 -437 57 -433L590 177Q590 178 557 222T452 366T322 544L56 909L55 924Q55 945 60 948Z"></path><path id="MJX-6-TEX-I-79" d="M21 287Q21 301 36 335T84 406T158 442Q199 442 224 419T250 355Q248 336 247 334Q247 331 231 288T198 191T182 105Q182 62 196 45T238 27Q261 27 281 38T312 61T339 94Q339 95 344 114T358 173T377 247Q415 397 419 404Q432 431 462 431Q475 431 483 424T494 412T496 403Q496 390 447 193T391 -23Q363 -106 294 -155T156 -205Q111 -205 77 -183T43 -117Q43 -95 50 -80T69 -58T89 -48T106 -45Q150 -45 150 -87Q150 -107 138 -122T115 -142T102 -147L99 -148Q101 -153 118 -160T152 -167H160Q177 -167 186 -165Q219 -156 247 -127T290 -65T313 -9T321 21L315 17Q309 13 296 6T270 -6Q250 -11 231 -11Q185 -11 150 11T104 82Q103 89 103 113Q103 170 138 262T173 379Q173 380 173 381Q173 390 173 393T169 400T158 404H154Q131 404 112 385T82 344T65 302T57 280Q55 278 41 278H27Q21 284 21 287Z"></path><path id="MJX-6-TEX-I-6F" d="M201 -11Q126 -11 80 38T34 156Q34 221 64 279T146 380Q222 441 301 441Q333 441 341 440Q354 437 367 433T402 417T438 387T464 338T476 268Q476 161 390 75T201 -11ZM121 120Q121 70 147 48T206 26Q250 26 289 58T351 142Q360 163 374 216T388 308Q388 352 370 375Q346 405 306 405Q243 405 195 347Q158 303 140 230T121 120Z"></path><path id="MJX-6-TEX-N-2C" d="M78 35T78 60T94 103T137 121Q165 121 187 96T210 8Q210 -27 201 -60T180 -117T154 -158T130 -185T117 -194Q113 -194 104 -185T95 -172Q95 -168 106 -156T131 -126T157 -76T173 -3V9L172 8Q170 7 167 6T161 3T152 1T140 0Q113 0 96 17Z"></path><path id="MJX-6-TEX-I-63" d="M34 159Q34 268 120 355T306 442Q362 442 394 418T427 355Q427 326 408 306T360 285Q341 285 330 295T319 325T330 359T352 380T366 386H367Q367 388 361 392T340 400T306 404Q276 404 249 390Q228 381 206 359Q162 315 142 235T121 119Q121 73 147 50Q169 26 205 26H209Q321 26 394 111Q403 121 406 121Q410 121 419 112T429 98T420 83T391 55T346 25T282 0T202 -11Q127 -11 81 37T34 159Z"></path><path id="MJX-6-TEX-N-22C5" d="M78 250Q78 274 95 292T138 310Q162 310 180 294T199 251Q199 226 182 208T139 190T96 207T78 250Z"></path><path id="MJX-6-TEX-I-6C" d="M117 59Q117 26 142 26Q179 26 205 131Q211 151 215 152Q217 153 225 153H229Q238 153 241 153T246 151T248 144Q247 138 245 128T234 90T214 43T183 6T137 -11Q101 -11 70 11T38 85Q38 97 39 102L104 360Q167 615 167 623Q167 626 166 628T162 632T157 634T149 635T141 636T132 637T122 637Q112 637 109 637T101 638T95 641T94 647Q94 649 96 661Q101 680 107 682T179 688Q194 689 213 690T243 693T254 694Q266 694 266 686Q266 675 193 386T118 83Q118 81 118 75T117 65V59Z"></path><path id="MJX-6-TEX-I-67" d="M311 43Q296 30 267 15T206 0Q143 0 105 45T66 160Q66 265 143 353T314 442Q361 442 401 394L404 398Q406 401 409 404T418 412T431 419T447 422Q461 422 470 413T480 394Q480 379 423 152T363 -80Q345 -134 286 -169T151 -205Q10 -205 10 -137Q10 -111 28 -91T74 -71Q89 -71 102 -80T116 -111Q116 -121 114 -130T107 -144T99 -154T92 -162L90 -164H91Q101 -167 151 -167Q189 -167 211 -155Q234 -144 254 -122T282 -75Q288 -56 298 -13Q311 35 311 43ZM384 328L380 339Q377 350 375 354T369 368T359 382T346 393T328 402T306 405Q262 405 221 352Q191 313 171 233T151 117Q151 38 213 38Q269 38 323 108L331 118L384 328Z"></path><path id="MJX-6-TEX-N-28" d="M94 250Q94 319 104 381T127 488T164 576T202 643T244 695T277 729T302 750H315H319Q333 750 333 741Q333 738 316 720T275 667T226 581T184 443T167 250T184 58T225 -81T274 -167T316 -220T333 -241Q333 -250 318 -250H315H302L274 -226Q180 -141 137 -14T94 250Z"></path><path id="MJX-6-TEX-I-70" d="M23 287Q24 290 25 295T30 317T40 348T55 381T75 411T101 433T134 442Q209 442 230 378L240 387Q302 442 358 442Q423 442 460 395T497 281Q497 173 421 82T249 -10Q227 -10 210 -4Q199 1 187 11T168 28L161 36Q160 35 139 -51T118 -138Q118 -144 126 -145T163 -148H188Q194 -155 194 -157T191 -175Q188 -187 185 -190T172 -194Q170 -194 161 -194T127 -193T65 -192Q-5 -192 -24 -194H-32Q-39 -187 -39 -183Q-37 -156 -26 -148H-6Q28 -147 33 -136Q36 -130 94 103T155 350Q156 355 156 364Q156 405 131 405Q109 405 94 377T71 316T59 280Q57 278 43 278H29Q23 284 23 287ZM178 102Q200 26 252 26Q282 26 310 49T356 107Q374 141 392 215T411 325V331Q411 405 350 405Q339 405 328 402T306 393T286 380T269 365T254 350T243 336T235 326L232 322Q232 321 229 308T218 264T204 212Q178 106 178 102Z"></path><path id="MJX-6-TEX-N-29" d="M60 749L64 750Q69 750 74 750H86L114 726Q208 641 251 514T294 250Q294 182 284 119T261 12T224 -76T186 -143T145 -194T113 -227T90 -246Q87 -249 86 -250H74Q66 -250 63 -250T58 -247T55 -238Q56 -237 66 -225Q221 -64 221 250T66 725Q56 737 55 738Q55 746 60 749Z"></path></defs><g stroke="currentColor" fill="darkred" stroke-width="0" transform="matrix(1 0 0 -1 0 0)"><g data-mml-node="math"><g data-mml-node="msub"><g data-mml-node="mi"><use xlink:href="#MJX-6-TEX-I-4C"></use></g><g data-mml-node="TeXAtom" transform="translate(681, -150) scale(0.707)"><g data-mml-node="mi"><use xlink:href="#MJX-6-TEX-I-43"></use></g><g data-mml-node="mi" transform="translate(715, 0)"><use xlink:href="#MJX-6-TEX-I-45"></use></g></g></g><g data-mml-node="mo" transform="translate(2036.2, 0)"><use xlink:href="#MJX-6-TEX-N-3D"></use></g><g data-mml-node="mo" transform="translate(3092, 0)"><use xlink:href="#MJX-6-TEX-N-2212"></use></g><g data-mml-node="mo" transform="translate(4036.6, 0)"><use xlink:href="#MJX-6-TEX-LO-2211"></use></g><g data-mml-node="msub" transform="translate(5647.3, 0)"><g data-mml-node="mi"><use xlink:href="#MJX-6-TEX-I-79"></use></g><g data-mml-node="TeXAtom" transform="translate(490, -150) scale(0.707)"><g data-mml-node="mi"><use xlink:href="#MJX-6-TEX-I-6F"></use></g><g data-mml-node="mo" transform="translate(485, 0)"><use xlink:href="#MJX-6-TEX-N-2C"></use></g><g data-mml-node="mi" transform="translate(763, 0)"><use xlink:href="#MJX-6-TEX-I-63"></use></g></g></g><g data-mml-node="mo" transform="translate(7255.2, 0)"><use xlink:href="#MJX-6-TEX-N-22C5"></use></g><g data-mml-node="mi" transform="translate(7755.5, 0)"><use xlink:href="#MJX-6-TEX-I-6C"></use></g><g data-mml-node="mi" transform="translate(8053.5, 0)"><use xlink:href="#MJX-6-TEX-I-6F"></use></g><g data-mml-node="mi" transform="translate(8538.5, 0)"><use xlink:href="#MJX-6-TEX-I-67"></use></g><g data-mml-node="mo" transform="translate(9015.5, 0)"><use xlink:href="#MJX-6-TEX-N-28"></use></g><g data-mml-node="msub" transform="translate(9404.5, 0)"><g data-mml-node="mi"><use xlink:href="#MJX-6-TEX-I-70"></use></g><g data-mml-node="TeXAtom" transform="translate(503, -150) scale(0.707)"><g data-mml-node="mi"><use xlink:href="#MJX-6-TEX-I-6F"></use></g><g data-mml-node="mo" transform="translate(485, 0)"><use xlink:href="#MJX-6-TEX-N-2C"></use></g><g data-mml-node="mi" transform="translate(763, 0)"><use xlink:href="#MJX-6-TEX-I-63"></use></g></g></g><g data-mml-node="mo" transform="translate(10803.2, 0)"><use xlink:href="#MJX-6-TEX-N-29"></use></g></g></g></svg>, where
     - binary indicator (0 or 1) if label $c$ is the correct classification for observation $o$
	 - predicted probability observation $o$ is of class $c$
	 - Penalty is logarithmic in nature yielding a large score for large differences close to 1 and small score for small differences tending to 0
]

---
# Machine Learning .darkblue[Ingredients: Model]

.more-more-condensed[
- .darkblue[Classification]
  - .darkblue[Binary] Classification
     - <span class="darkblue"><span class="material-icons">email</span> $\overset{?}{\rightarrow}$ <span class="material-icons">delete</span> SPAM</span>-Detection: use emails seen so far to produce rules to predict whether future emails are spam or not
  - .darkblue[Multi-Class] Classification
     - <span class="darkblue"><span class="material-icons">scanner</span> <span class="material-icons">east</span> <span class="material-icons">description</span> Optical character recognition (OCR)</span> in handwritten text: Learn patterns from data and classify new data
  - .darkblue[Multi-Label] Classification
     - <span class="darkblue"><span class="material-icons">email</span> <span class="material-icons">east</span> <span class="material-icons">groups</span> Text Classification</span>: assign customer communications to employees in different departments
- .darkblue[Regression]
  - <span class="darkblue"><span class="material-icons padding-left">thermostat</span>Weather Forecast: Predicting values</span> based on relevant information
- .darkblue[Clustering]
  - <span class="darkblue"><span class="material-icons padding-left">shopping_cart</span>Identify consumers with similar behavior</span> (e.g. for marketing purposes)
- .darkblue[Generate data]
  - <span class="darkblue"><span class="material-icons padding-left">description</span><span class="material-icons">east</span><span class="material-icons">image</span>Learn patterns or structure from data and reproduce them</span> (e.g. generate pictures from descriptions, compose music)
]

---
# .darkblue[Supervised Learning: Data]

.reference[Adapted from <a href="https://github.com/qiskit-community/qiskit-presentations/tree/master/2021-11-29_12-02_eqtc" target="_blank">A. Dekusar, J. Gacon, Qiskit Machine Learning: Quantum algorithms for supervised learning, EQTC, 2022</a> Picture Sources: <a href="https://pixabay.com/de/vectors/katze-tier-die-silhouette-au%c3%9fer-1583462/" target="_blank">Cat</a> <a href="https://pixabay.com/de/vectors/hund-tier-silhouette-5890164/" target="_blank">Dog</a>]

<table>
<tbody>
<tr>
<td style="vertical-align:top;width:65%">
.more-more-condensed[
 - .darkblue[Classify] whether the picture contains a .darkblue[cat or dog] based on certain features of animals:<br/>1. Dataset: $\\{(x_1,y_1),...,(x_N,y_N)\\}$
   - .darkblue[$x_i$: features]
   - .darkblue[$y_i$: labels] (i.e., cat or dog)

<table class="small-font">
<tbody>
<tr>
<td></td>
<td class="textcenter"><img src="../../img/qc/ml/cat-g88698f70e_640.jpg" align="top" style="width:3em"></img></td>
<td></td>
<td></td>
<td></td>
<td class="textcenter"><img src="../../img/qc/ml/dog-g5f8fc564b_640.jpg" align="top" style="width:4em"></img></td>
<td></td>
</tr>
<tr>
<td>$x_i=$</td>
<td>$\left[\begin{array}{c} x_{i,1} \\ x_{i,2} \\ \vdots \\  x_{i,k} \end{array}\right]$</td>
<td>$y_i=1$</td>
<td style="width:1em"></td>
<td>$x_j=$</td>
<td>$\left[\begin{array}{c} x_{j,1} \\ x_{j,2} \\ \vdots \\  x_{j,k} \end{array}\right]$</td>
<td>$y_i=-1$</td>
</tr>
<tr>
<td colspan="7" class="textcenter"><span class="darkblue">Dataset with $k$ features</span> like weight, tail length, ...</td>
</tr>
</tbody>
</table>

]
</td>
<td style="vertical-align:top" style="width:35%">
.more-more-condensed[
- .darkblue[Split] the dataset .darkblue[into] the .darkblue[training and test datasets]<br/>
<table style="border-collapse:collapse">
<tbody>
<tr>
<td style="background-color:DeepSkyBlue;width:3em;height:7em"></td>
<td class="small-font padding-left">70% Training dataset with<br/>$t$ samples<td>
</tr>
<tr>
<td style="background-color:SteelBlue;width:3em;height:3em"></td>
<td class="small-font padding-left">30% Test dataset with<br/>$u$ samples</td>
</tr>
<tr>
<td colspan="2">$N=t+u$</td>
</tr>
</tbody>
</table>
]
</td>
</tr>
</tbody>
</table>

---
# .darkblue[Supervised Learning: Model]

.more-more-condensed[
- .darkblue[Classify] whether the picture contains a .darkblue[cat or dog] based on certain features of animals:
<ol start="2"><li class="small-font32"><span class="darkblue">Linear Model<br/>$\hat{y}=f(x,\Theta)=\Theta^T\cdot x$</span><br/><span class="small-font28">Dimensionality of the vectors: $k$ (=number of features)<div class="round-border blue-border darkblue">Estimating the predicted label $\hat{y}$ by feeding a sample from the dataset and comparing $\hat{y}$ versus ground truth value $y$ from the dataset</div></span></li>
]

---
# .darkblue[Supervised Learning: Cost]

.more-more-condensed[
- .darkblue[Classify] whether the picture contains a .darkblue[cat or dog] based on certain features of animals:
<ol start="3"><li class="small-font28"><span class="darkblue">For the $t$ samples in the training dataset compute cost with
<ol style="list-style-type:lower-latin"><li>Mean Squared Error (MSE): $C_{MSE}=\frac{1}{t}\cdot\sum_{i=1}^t(\hat{y}_1-y_i)^2$</li>
<li>Binary classification (e.g., "cat" or "dog") using cross-entropy loss:<br/><img src="../../img/qc/ml/BinaryCrossEntropyLoss.svg" align="top" class="fullwidth padding-top"></img></li></ol></li><li>...</li></ol>
</span></li></ol>

.darkblue[.bold[Minimize] the] chosen .darkblue[cost function to have a good model $f(x_i,\Theta)$]
]

---
# How can we .darkblue[build] a .darkblue[quantum model]?

.reference[<a href="https://doi.org/10.1038/s41586-019-0980-2" target="_blank">Havlíček et al. Supervised learning with quantum-enhanced feature spaces. Nature 567, 209–212, 2019</a>]

.more-more-condensed[
<div class="textcenter">
<img src="../../img/qc/ml/QuantumModelModel.svg" align="top" class="fullwidth"></img>
</div>
]

---
# How can we .darkblue[build] a .darkblue[quantum model]?

.reference[Adapted from <a href="https://github.com/qiskit-community/qiskit-presentations/tree/master/2021-11-29_12-02_eqtc" target="_blank">A. Dekusar, J. Gacon, Qiskit Machine Learning: Quantum algorithms for supervised learning, EQTC, 2022</a> <a href="https://doi.org/10.1088/2058-9565/ab4eb5" target="_blank">[B+'19]</a> <a href="https://doi.org/10.1038/s41467-021-22539-9" target="_blank">[H+'21]</a>]

.more-more-condensed[
<table class="tablesmallpadding">
<tbody>
<tr>
<td style="width:30%">.darkblue.bold[Solution Space]</td>
<td style="width:70%">.darkblue[.bold[Hardware-efficient] Ansatz]</td>
</tr>
<tr>
<td><img src="../../img/qc/ml/ChoosingAnsatz.svg" align="top" class="fullwidth"></img></td>
<td><img src="../../img/qc/ml/HardwareEfficientAnsatz.svg" align="top" class="fullwidth"></td>
</tr>
<tr>
<td colspan="2">.darkblue[.bold[Problem-specific] ansatz]</td>
</tr>
<tr>
<td colspan="2" class="small-font24">.darkblue[Use knowledge about problem to choose ansatz!]</td>
</tr>
<tr>
<td colspan="2" class="small-font24">Example: Does the .darkblue[wave function of the quantum states only] have .darkblue[real amplitudes]?</td>
</tr>
<tr>
<td colspan="2" class="small-font24">.darkblue[Many different quantum circuits] for machine learning models, see [B+'19]</td>
</tr>
</tbody>
</table>
]

---
# .darkblue[Variants]

.reference[<a href="https://doi.org/10.1002/qute.201900070" target="_blank">[SJA'19]</a>]

.more-more-condensed[
<table class="tablesmallpadding result">
<tbody>
<tr>
<th style="width:20%">Entanglement Layer</th>
<th style="width:20%">Linear</th>
<th style="width:24%">Circular</th>
<th style="width:36%">Fully Connected</th>
</tr>
<tr>
<th>Circuit</th>
<td><img src="../../img/qc/ml/LinearEntanglementLayer.svg" align="top" class="fullwidth"></img></td>
<td><img src="../../img/qc/ml/CircularEntanglementLayer.svg" align="top" class="fullwidth"></td>
<td><img src="../../img/qc/ml/FullyConnectedEntanglementLayer.svg" align="top" class="fullwidth"></td>
</tr>
<tr>
<th>#Gates for $n$ qubits</th>
<td><span class="katex"><span class="katex-mathml"><math><semantics><mrow><mi>n</mi></mrow><annotation encoding="application/x-tex">n</annotation></semantics></math></span><span class="katex-html" aria-hidden="true"><span class="strut" style="height: 0.43056em;"></span><span class="strut bottom" style="height: 0.43056em; vertical-align: 0em;"></span><span class="base"><span class="mord mathit">n</span></span></span></span> − 1</td>
<td>$n$</td>
<td>$\binom{n}{2}$</td>
</tr>
</tbody>
</table>

- .darkblue[Different combinations of x ,y and z] rotation gates in the rotation layer
- In variants .darkblue[rotation layer and entanglement layer are combined into] one by using .darkblue[controlled rotation gates]
]

---
# .darkblue[Retrieving the result of a Quantum Model] - Measurement

---
# .darkblue[Result of a Quantum Model] - Measurement

.more-more-condensed[
<table>
<tbody>
<tr>
<td style="width:70%">
<div class="textcenter">
<img src="../../img/qc/bloch/MeasurementSuperposition.svg" align="top" class="fullwidth"></img>
</div>
</td>
<td class="darkblue" style="width:30%">
.small-font[$|\psi\rangle=\alpha|0\rangle+\beta|1\rangle$]<br/>.small-font[$|\alpha|^2+|\beta|^2=1$]
</td>
</tbody>
</table>
<table class="tablesmallpadding small-font fullwidth">
<tbody>
<tr>
<td class="bold darkblue textcenter" style="width:30%">Measure $x$ samples:</td>
<td class="bold darkblue textcenter" style="width:70%">Expectation value:</td>
</tr>
<tr>
<td class="textcenter"><table><tbody><tr><td>e.g., $x$=1000:</td><td><img src="../../img/qc/ml/SampleCount.svg" align="top" style="width:6em"></img></td></tr></tbody></table></td>
<td class="darkblue textcenter" style="vertical-align:top">.em[Average value of all results of a quantum operator] $Z$ (with eigenvectors $\phi_i$ and eigenvalues $a_i$) applied to a state $\psi$:<br/>$\langle Z\rangle_\psi=lim_{n\rightarrow\infty}\sum\frac{N_i}{N}a_i=\sum|\langle \phi_i|\psi\rangle|^2 a_i=\langle\psi|Z|\psi\rangle$<br/>e.g.: $\langle Z\rangle=1\cdot P_0+(-1)\cdot P_1$</td>
</tr>
</tbody>
</table>
]

---
# .darkblue[Post-Processing]

.more-more-condensed[
<table class="tablepadding">
<tbody>
<tr>
<td class="darkblue bold">Sampling-based</td>
<td>
</td>
<td>
</td>
</tr>
<tr>
<td class="round-border blue-border padding textcenter"><img src="../../img/qc/ml/SampleCount3bits.svg" align="top" style="width:6em"></img></td>
<td><table class="textcenter fullwidth"><tbody><tr><td>.darkblue[mapping]</td></tr><tr><td><svg-arrow scale="0.1" orientation="right" color="darkblue"></svg-arrow></td></tr><tr><td>e.g. parity: even or<br/>odd number of 1s?</td></tr></tbody></table></td>
<td class="round-border blue-border padding">.darkblue[label]<br/><br/>0 with $P_{010}$<br/>1 with $P_{110}$</td>
</tr>
<tr>
<td class="darkblue bold padding-top">Expectation-based</td>
<td>
</td>
<td>
</td>
</tr>
<tr>
<td class="round-border blue-border padding darkblue textcenter">Measure expectation<br/>value<br/><br/>$\langle z_1\cdots z_n\rangle=-0.5$</img></td>
<td><table class="textcenter fullwidth"><tbody><tr><td>.darkblue[mapping]</td></tr><tr><td><svg-arrow scale="0.1" orientation="right" color="darkblue"></svg-arrow></td></tr><tr><td>e.g. sign</td></tr></tbody></table></td>
<td class="round-border blue-border padding">.darkblue[label]<br/><br/>1 with $Pr=\frac{1+0.5}{2}$</td>
</tr>
</tbody>
</table>
]

---
# .darkblue[Join Ordering] with .darkblue[Quantum ML]

.reference[<a href="https://doi.org/10.1145/3579142.3594299" target="_blank">Winker,Çalıkyılmaz,Gruenwald,Groppe, Quantum Machine Learning for Join Order Optimization using V. Q. C., BiDEDE@SIGMOD'23</a>]

<div class="more-more-condensed">
<ul><li>Compared to ML: <a href="https://doi.org/10.1038/s41467-022-32550-3" target="_blank">Learning with fewer data, higher accuracy</a></li></ul>
<div class="textcenter">
<img src="../../img/qc/ml/QuantumModel.svg" align="top" style="width:97%"></img>
</div>

<table class="fullwidth textcenter">
<tbody>
<tr>
<td>.bold[Input:] .darkblue[Relations]</td><td>Trained Model</td><td>.bold[Output:] .darkblue[Join Order]</td>
</tr>
<tr>
<td></td><td></td><td></td>
</tr>
</tbody>
</table>
<div class="textcenter">
<img src="../../img/keynotes/bv/JOOQMLInOut.svg" align="top" class="fullwidth"></img>
</div>
</div>

---
# .darkblue[Join Ordering] with .darkblue[Quantum ML]

.reference[ErgastF1 benchmark joining 4 relations, <a href="https://doi.org/10.1145/3579142.3594299" target="_blank">Winker,Çalıkyılmaz,Gruenwald,Groppe, QML for Join Order Opt. using VQCs, BiDEDE@SIGMOD'23</a>]

---
# .darkblue[Is quantum ML better than classical ML?]

.reference[Adapted from <a href="https://doi.org/10.1038/s41467-021-22539-9" target="_blank">[H+'21]</a> Quantum speed-up in supervised machine learning: <a href="https://doi.org/10.1038/s41567-021-01287-z" target="_blank">[YAT'21]</a>]

---
# .darkblue[Summary & Conclusions]

.more-more-condensed[
- .darkblue[Machine Learning]
  - Basics: .darkblue[Data, Model, Cost]
- .darkblue[.bold[Quantum] Machine Learning]
  - .darkblue[Data Encoding/Feature Maps]
     - <span class="darkblue">Basis</span> Encoding
	 - .darkblue[Amplitude] Encoding
	 - .darkblue[Angle] Encoding
	 - .darkblue[Higher-Order] Encodings
  - .darkblue[Quantum Model]
     - <span class="darkblue">Hardware-efficient Ansatz</span>
  - .darkblue[Result] of a Quantum Model .darkblue[via Measurement]
     - <span class="darkblue">Sampling versus expectation value</span>
	 - .darkblue[Post-processing]
]
